Fog light setting/Avtivate fog light
Foglight setting
Price
Foglight at position 1 or2 and whith high beam
295 SEK
Foglight at position 2 and whith high beam
295 SEK
Foglight at position 1 or2
295 SEK
- Secure payment by card
- Do you have any questions. Contact us via webshop
Original number is just for referens
- Car model:SAAB 9-3 2003-2012
- Ref:OBD cabel low speed (pin1 & 5) blue OBD connects to interface like this Can high pin 7 connects to pin 1 in cars OBD socket Can low pin 2 connects to pin 5 in cars OBD socket GM MDI Controls internaly what pin in obd socket to use
- Spec:Activate foglight function Foglight setting at light switch position Variant 1: Foglight at position 1 or2 and whith high beam Variant 2: Foglight at position 2 and whith high beam Variant 3: Foglight at position 1 or2
- More info:CAN interface is required to perform programming and is not included in the price. Loan interface can be sent against a deposit cost of SEK 1,500 which is credited after return. A link to the manual and program can be found in end of article page. A separate email with the license file will be sent to your email. Can interface supported are: GM MDI Kwaser Peak system can interface Lawicel CAN USB ETAS Can interface Vector Can interface
- Contains:Windows8 or newer 64bit PC Software to program UEC. Own or borrowed interface required. The license file that is sent to you via email after ordering is locked to the registration/Vin number you enter when ordering. This service is not subject to cancellation or return rights.
Description
Article no.: 315.3000
•Foglight settings
<
br>•Activate fogligt function
<
br>SAAB 9-3 2003-2012
Files and media
 | ECU Configiurator manual and download page |
